Model:NAV16036 (Eliminated)


  • ONVIF Profile S, LILIN IP cameras, PTZ domes, and DVRs/NVRs are supported.
  • Up to 36 channels 1080P/3M/4M/5M/8M Network streaming, recording, and display
  • Built-in hardware RAID system, support up to 16 x 3.5" hot-swap HDDs.
  • Failover, video achieve, record file sync. and SmartSearch support.
  • Dual streamings decoding mode supported
  • Support multi-channels playback/record file backup for remote or local.
  • Built-in dual port Gigabit Ethernet.


LILIN NAV16036 36 Channel Recorder supports LILIN IP cameras, PTZ domes, and DVRs/NVRs. The recorder features    up to 36 channels 1080P/3M/4M/5M/8M network streaming, recording, and display, built-in dual port Gigabit Ethernet, and dual monitors support. It also supports multi-channels playback for remote or local. NAV16036 is capable of supporting multi-camera installations where LILIN cameras are installed, and NAV delivers a solid surveillance platform with offering all the basic features, as well as some of the more advanced ones that a basic security system requires.

ePTZ feature and ePOS integration are also provided for free of charge. The maximum video speed can perform 3,840X2,160 at 30 frames per second, and support up to 2 monitors. Keyboard is controllable via RS-485 for PTZ, ePTZ, and ROI region of interest features. Two-way audio and recording are available.
