| Tier Architecture Administrative System | Support multi-layer tree structure management system, up to 64 layers, each layer up to 64 NAV servers |
| Authentication | Camera access and function access right manageable |
| NAV Recorder Management | Simultaneously controls up to 4096 NAV Corportate version recording servers |
| IP Device Management | Simultaneously controls up to 65000 LILIN IP cameras, IP speed domes, DVR/DHD/NVR and NAV Live servers |
| Supports (Video Input)/Network video /IP video | LILIN IP camera, speed dome, DVR/DHD/NVR, NAV recorder |
| Maximum Network Throughput | Upload: up to 5000Mbps, Download: up to 5000Mbps (based on hardware specifications) |
| Recording Resolution | Max 12MP@20 fps, 8MP@30 fps, 5MP@30 fps, 4MP@30 fps, 3MP@30 fps, 1080p@120 fps, and ROI recording supported |
| Digital zoom | Live and recorded videos (PTZ/ePTZ) |
| OSD (On-Screen Display) | People counting/object counting/tripwire detection/license plate/POS string |
| PTZ Control | Yes, on-screen PTZ control and button control |
| Playback Search | Time search, event search, date search, smart transaction search, smart playback, license plate recognition |
| Playback Resolution | 3840 × 2160, 2592 × 1944, 2048 × 1536, 1920 × 1080, 1280 × 1024, 1280 × 768, 720 × 480, 720 × 576, 320 × 240 |
| Playback Speed | Fast Rewind: 1/8, 1/4, 1/2, 1X, 2X, 4X, 8X, 16X, 32X
Fast Forward: 1/8, 1/4, 1/2, 1X, 2X, 4X, 8X, 16X, 32X |
| Backup / Playback (Software) | Up to 36 channels, exportable to AVI or MP4 file |
| Multiple channel playback | Up to 144 channels |
| Remote DVR/NVR Video | Supports NAV recorder/Navigator/DVR/DHD/NVR/IP camera/SD card for remote video playback; up to 144- channel playback and 36-channel backup |
| Playback compression | H.265/ H.264 /JPEG |
| MJPEG Transcoding | Integrated with third party suppliers |
| Split Screen | 1, 4, 9, 16, 25, 36, 49, 64, 81, 100, 121, 144, or user defined template |
| Dual stream technology (Video output) | Split screen D1 decoding, full screen 1080p/3M/4M/5M/8M/12M decoding |
| Alarm Triggering | Full screen alarm, PC alarm sound, DO output for designated IP camera alarm, e-mail snapshot output, PTZ preset position output, acknowledgment to TV wall, blinking mark at e-Map |
| Number plate recognition | Yes (optional) |
| POS / barcode scanner | Yes |
| NAV Operation Status | CPU, connection & recording status, HDD status |
| Digital Output | Supports TCP/IP output for 3rd party suppliers |
| RAID failure notification | Supported |
| Device management | IP Scan to detect LILIN IP products; User definable device groups to view |
| Database | Database import and exports, CSV table import/output for maintenance |
| Event search filter | Yes |
| Access log | Complete reports for database administration operations |
| Video decoder | LILIN VD022 for video wall |
| (TV Wall)Physical monitors | Up to 1440 physical remote monitors supported by network (based on number of video output available on external graphic card from dedicated server) |
| (TV Wall)Rooms of the wall | 199 rooms supported for various monitor layouts |
| Video Wall Monitor | Each room can allocate up to 144 monitors to be combined freely |
| (TV Wall)Channel groups | 128 channel groups per room to layout various channels within the same |
| Video Channel | Up to 144 channels per TV wall group |
| Video Wall | Up to 144 channels per monitor, resolutions up to 12M |
| Sequence Mode | Supported |
| Centralized device management | Supported |
| User/Group Administration | Supported |
