Device Hub
Model：DH032
- Use your mobile phone for monitoring all device statuses for client sites
- Remote reboot the device restoring back to work as needed
- No more rush to a client site for maintenance
- Plan client sites visiting for maintenance afterwards
- Centralized client sites management with AWS redundancy
- iOS and Android for device maintenance push notification
- HTTPs communication and encrypted database cloud computing
- Customize your company logo for end user Apps
- Support dashboard for quick managing devices at client sites
- Auto scan your network IP cameras and NVRs
- Auto update to LILIN Device Cloud from client sites
- Plug-n-play, no P2P, no port forwarding Forwarding
- LILIN WebSmart PoE switch supported for power reboot
- Support HDMI and mouse for local management
The DH032 is an IP device management hub built on an ARM Cortex A9 600 MHz processor with Linux, carrying one Gigabit Ethernet port and HDMI 1920 by 1080p output, managing up to 128 ONVIF or LILIN IP cameras. IP scanning auto-discovers and configures camera addresses, supports remote access to LILIN NVR and DVR recordings, and integrates control of PoE switches PS3108C, PS3188C and PS3268C. The dashboard displays recording, online, offline and video loss status in real time, and devices respond to Alexa voice commands for doors, gates, NVR and PTZ with remote camera reboot available. The 183 by 130 by 43 mm chassis weighs 0.5 kg, runs on DC12V 1.5A 18W from 0°C to 45°C, and provides English, Traditional Chinese and Italian interfaces.
