| Supports (IP Video input) | AHD / CVI / TVI / Analog camera / LILIN IP camera |
| Input (Video input) | 16 CH |
| Simulation HD / Analog Camera Input Resolution(Video input) | TVI, CVI, AHD 4MP / 1080p / 720p and analog camera D1 / 960H |
| Simulation HD / Analog Camera Maximum Input Frame Rate (Video input) | 4M 240 / 200 fps 1080p 480 / 400 fps 720p 480 / 400 fps 960H 480 / 400 fps |
| Network Camera Resolution(Video input) | 4M、3M、1080p、720p |
| Network Camera Maximum Input Frame Rate(Video input) | Single Channel 4M 15 fps / 3M 15 fps / 1080p 30 fps |
| Video output | HDMI 4K, VGA 1080p, CVBS |
| Split Screen | 1 / 4 / 9 / 13 / 16 split division, sequence mode, freeze |
| Digital zoom | Up to 5× on live and playback |
| Privacy Masking | Each channel 4 privacy mask supported |
| Record Encode | H.264 |
| Record Resolution | CIF ~ 4Mega |
| Simulation HD / Analog Camera Maximum Recording Frame Rate( Recording ) | 4MP 120 / 100 fps 1080p 240 / 200 fps 720p 480 / 400 fps 960H 480 / 400 fps |
| Maximum Network Camera Input Throughput(Recording) | 80Mbps |
| Network Camera Maximum Recording Frame Rate | 4M 240 fps , 3M 240 fps , 1080p 480 fps |
| Application/ Recording Mode | Continue, Schedule, Event |
| Recording schedule | 4 schedule, 7day × 24 hours time table |
| Alarm event actions | Adjustable motion area (100 level sensitivities) / System / Video loss |
| Alarm Notification (Recording) | Alarm notification iOS, android / E-Mail / FTP / buzzer |
| Playback Search | Event / Time / Smart search |
| Playback Display | 16CH synchronous playback |
| Playback Resolution | CIF ~ 4Mega |
| Playback Speed | Fast rewind 4×~32× / Fast forward 4×~32× / Step Forward / Slow motion 1/2~1/8 |
| Internal HDD (Storage) | 2 × 3.5” HDD, each up to 8TB supported |
| USB Flash Disk(Backup) | Up to 32 GB supported |
| Network Backup | Via HTTP |
| Analog Audio Input(Audio) | 4 CH, RCA × 4 |
| Audio Output | RCA × 1 (0.7Vp-p, 300 Hz to 3KHz) |
| Network ports | RJ-45 Gigabit Ethernet × 1 |
| Protocols | ARP / TCP/IP / UDP / HTTP / SMTP / FTP / DDNS / PPPoE / NTP / DHCP/ Onvif Profile S |
| Web (Network) | Direct internet browser access / Multiple users access |
| P2P(Network) | QR Code App scan / UID connection( Need additional option ) |
| Mobile Application | iOS / Android supported |
| VMS support | CMS |
| Backup / Playback (Software) | IE / Remote control software |
| Reports( System ) | Alarm event, operation and configuration log full reports exporting over HTTP or USB |
| Authentication ( System ) | User authentication with feature configurable |
| Languages | Arabic / Bulgarian / Chinese( Simplified ) / Chinese ( Traditional ) / Croatian / Czech / Dutch / English / French / German / Greek / Hebrew / Indonesian / Italian / Japanese / Korean / Latvia / Persian / Polski / Portuguese / Romanian / Russian / Spanish / Thai / Turkish / Vietnamese |
| HDD Inspection(System) | S.M.A.R.T monitoring |
| Recorded Reserve Time( System ) | Adjustable 1~9999 hours |
| Time | Daylight saving / NTP |
| Mouse | Mouse click, drag and scroll |
| PTZ protocol | RS-485 × 1, MLP1、MLP2、PELCO D、PELCO P、SAMSUNG、LG-MULTIX , LILIN IP camera |
| UTC | Up The Coax AHD camera supported |
| CPU | ARM Cortex A9 Dual Core |
| OS | Embedded Linux Kernel 3.1 |
| Watchdog | Hardware watchdog timer |
| Operating temperature | 0℃ ~ 40℃ |
| Operating humidity | 5% ~ 80% |
| Dimensions | 354× 230 × 45 mm |
| Weight | ≈1.5 KG (Without hard drive) |
| Power Supply | Adapter DC 12V, 5A, 60W × 1 |
| Warranty | 2 Years |
