100 Meter PT White LED Illuminator

The IM57114AE is a 100 meter PT white LED illuminator using a high power laser LED with ultra white 6500K output, delivering 100,000 Lux ±10% at 3.5 meters at 1.6 degrees. Beam angle adjusts from 1.6 to 11 degrees, panning is 360 degrees endless and tilting spans -30 to +210 degrees, with manual speeds from 0.5°/s to 120°/s in eight steps and preset speeds from 1°/s to 300°/s. It draws power from PoE++ (IEEE 802.3bt) or DC 21 to 35V, consuming 29W with illumination off and 45W on. The Ø184 by 368 mm aluminum and polycarbonate housing weighs 6 kg, operates from -25°C to +60°C, is rated IP67 and IK10, supports Digest HTTP authentication and ONVIF control, and updates over HTTP and IP Scan.
