| Pick Up Element | 1/2.8" CMOS image sensor |
| Effective pixels | 2096 (H) x 1561 (V) = 3,271,856 (pixel) |
| Video Compression | H.264 , Motion JPEG |
| Resolution | 3MP(2048 x 1536), 1080p(1920 x 1080), 720p(1280 x 720), D1(720 x 480), CIF(352 X 240) |
| Maximum Frame Rate | H.264 : up to 30 fps @ 1920 x 1080, MJPEG : up to 30 fps @ 720 x 480 / H.264 : up to 30 fps @ 1280 x 720, MJPEG : up to 30 fps @ 352 x 240 / H.264 : up to 30 fps @ 1920 x 1080, MJPEG : up to 30 fps @ 1280 x 720 / H.264 : up to 30 fps @ 720 x 480, MJPEG : up to 15 fps @ 1920 x 1080 / H.264 : up to 15 fps @ 2048 x 1536, MJPEG : up to 15 fps @ 720 x 480 |
| Focal Length | 2.8〜12 mm |
| Iris | F1.4 |
| Angle of View | 91.2° 〜25.5°(H), 59.4° – 22.4°(V), 99° – 37.3°(D) |
| Max IR distance | 25m |
| Infrared LED Angle | 30∘ |
| Video streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video bitrate | 128Kbps〜8Mbps ; Frame rate and bit rate controllable on-the-fly ; VBR / CBR / GOP supported |
| Peak wavelength | 850nm |
| Scanning System | Progressive Scan |
| Infrared Cut Filter | Colour (Day), Monochrome (Night), Auto, Schedule |
| Min. illumination/Low Light Mode (Colour) | 0.15 Lux at F1.4 (Low light mode) / 0 Lux with IR LED on |
| White Balance | Auto / Tungsten / Indoor / Fluorescents1 / Fluorescents2 / Outdoor1 / Outdoor2 |
| Back Light Compensation (BLC) | Off / On |
| Electrical Shutter | 1/30(1/25)s〜1/8000s |
| Sense Up | Off / 1 frame / 2 frames / 3 frames / 7 frames |
| Sense Up+ | Yes |
| Auto Gain Control | 36 dB variable gain |
| 3D Noise Reduction | Off / 1〜32 selectable |
| 2D WDR | Off / Auto / x2 / x3 / |
| Privacy Masking | Off / On (4 zones) |
| Other functions | Brightness, Contrast, Hue, Saturation, Sharpness, Mirror, Flip |
| Live Video Output | CVBS 1.0Vp-p, 75 ohm, RCA connector |
| Audio Input / Output | Mono, 1.4 Vp-p , 50 KΩ , Terminal connector |
| User accounts | Base64 HTTP encryption |
| Access | Multiple user access levels with password protection |
| Encryption | 10 user accounts available |
| IP address filter | Yes |
| Multi IP address | Yes |
| User accounts | 8 simultaneous users |
| ePTZ & Digital Zoom | Yes, ROI is supported |
| OSD (On-Screen Display) | Text overly for date, time , and camera name |
| Alarm event triggers | Motion / Tamper / Audio / Alarm / Face detection / Network lost detection |
| Alarm event actions | FTP / SMTP / HTTP post / SD card / SAMBA / SNMP Trap / Alarm Output / Push Service notification |
| CPU | Embedded SoC ARM11, 528MHz, 256MB DDR2, 256MB flash memory |
| Firmware | Firmware upgrade via HTTP / Firmware available to download at meritlilin.com |
| Network Interface/Ethernet | 10/100 Mbps Base-T (Tx), RJ-45 |
| CE | Yes, EMI Class A |
| FCC | Yes, EMI Class A |
| OS requirement | Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8 |
| Web browser | Microsoft® Internet Explorer® 6 and later |
| CPU requirement | Intel Pentium 4 1.8GHz or above |
| RAM requirement | 1GB or above ,Independent Display Card |
| Protocols | IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SNMP, SIP, Bonjour |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro) iPhone, iPad, Android support |
| Video Management | ONVIF Profile S / LILIN CMX3.6 NAV 1.0 / Third party VMS through LILIN HTTP API |
| Video Display | LILIN Universal ActiveX & LILIN Java Applet |
| OS | Embedded Linux 2.6.32 |
| Audio | Two-way Audio, G.711 u-law / PCM, External Microphone Required |
| SD Card (recording) | Support Micro SD/SDHC card for circular recording (card is not included) |
| Alarm Input / output | Digital 1 input (TTL, +3〜5VDC) / 1 Output (MOS Relay contact N.O., Load max. 40VDC/300mA) |
| IP Rating | IP67 waterproof |
| Vandal Resistant Rating / IK Rating | IK10 vandal proof |
| Operating temperature | -40°C〜+50°C (-40°F〜122°F) |
| Dimensions | Ø 145 x 130mm |
| Weight | 1000g approx. |
| Power Supply | DC12V ±10%。PoE (IEEE 802.3af compliant) |
| PoE | PoE |
| Power Consumption | DC12V, 9W / PoE, 10.2W |
