| Min. illumination/Low Light Mode (Colour) | 0.5 lux (1/30 sec, F1.6(Wide), 50IRE, AGC-Gain: 30dB ICR-OFF) 0.1 lux (1/30 sec, F1.6(Wide), 50IRE, AGC-Gain: 30dB ICR-OFF) 0.2 lux (1/8 sec, F1.6(Wide), 50IRE, AGC-Gain: 30dB ICR-OFF) 0.01 lux (1/8 sec, F1.6(Wide), 50IRE, AGC-Gain: 30dB ICR-OFF) |
| High Dynamic Range(HDR) | Up to 90dB |
| Power Consumption | PoE+, 14W (does not support the heater) AC24V, 37W (Heater ON) |
| Power Supply | PoE+ (IEEE 802.3at compliant) / AC24V ±10% |
| Pick Up Element | 1/2.8" CMOS image sensor |
| Effective pixels | Effective pixels : 1944 (H) × 1224 (V) = 2,379,456 (pixels) ; Total number of pixels : 1952 (H) × 1236 (V) = 2,412,672 (pixels) |
| CE | Yes, EMI Class A |
| FCC | Yes, EMI Class A |
| IP Rating | IP66 waterproof |
| Vandal Resistant Rating / IK Rating | IK10 impact resistant |
| Focal Length | 4.3mm (WIDE) - 129mm (TELE) |
| Minimum Aperture Ratio | 1:1.6 (WIDE)-5.0 (TELE) |
| Minimum object distance | 10cm (WIDE end), 1.5M (TELE end) |
| Iris Range | F1.6 – 32 , Close |
| Angle of View | Approx. 64.45°( H ) 39.27°( V ) (WIDE end), approx. 2.41°( H ) 1.36°( V ) (TELE end), (1080p mode) |
| Panning Range | 360° Endless |
| Panning Mode | Manual , Auto , Manual Position , Sequential Position |
| Panning Speed | Manual Approx. 0.1°/s - 120°/s 8 Steps, Preset Approx. 1°/s - 255°/s, Alarm Trigger Speed 360°/s |
| Tilting Range | -6° - +96° |
| Tilting Mode | Manual , Auto , Manual Position , Sequential Position |
| Tilting Speed | Manual approx. 0.15°/s-120°/s 8 Steps, 16 Steps / Preset approx. 1°/s -255°/s, Alarm Trigger Speed 360°/s |
| Operating temperature | -10°C-+ 50°C (14°F-122°F) / PoE+ ; - 40°C-+ 50°C ( -40°F-122°F) / AC |
| Operating humidity | 0% - 90% |
| CPU | Intel® Core™ i3 or higher grade |
| OS | Windows 7 or above |
| RAM | 4GB or above, Dedicated Graphics Card |
| Web browser | Microsoft® Internet Explorer® 9.0 and later |
| Dimensions | 332 (H) × 210 (D) mm |
| Weight | 3200g approx. |
| Video Compression | H.264 , Motion JPEG |
| Video streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video bitrate | 128 Kbps to 8 Mbps ; Frame rate and bitrate controllable on-the-fly ; VBR / CBR / GOP supported |
| Resolution | 1080p HD( 1920 x 1080 ) , 720p HD( 720p HD ) , D1( 720 x 480, 720 X 576 ) , CIF( 352 x 240 ) |
| Maximum Frame Rate | H.264: up to 30 fps @ 1920 x 1080 ; Motion JPEG: up to 30 fps @ 720 x 480 |
| Infrared Cut Filter | Colour (Day), Monochrome (Night), Auto |
| Scanning System | Progressive Scan |
| White Balance | ATW/Indoor(3200K)/Outdoor(5800K) /Manual(1800K ~10500K) |
| Electrical Shutter | Auto / manual(1/1 to 1/100,000) |
| Exposure Mode | Auto / Manual |
| Back Light Compensation (BLC) | Off / BLC / WDR |
| 3D Noise Reduction | Off / On (2D, 3D) |
| Privacy Masking | Off / On (up to 16 areas) |
| Auto Mode | OFF / AUTO / SEQ / TOUR |
| PTZ Control | Pan, tilt, zoom-in / zoom-out, absolute position, and mouse click function |
| Schedule Setting | Off / Auto Mode / Preset position |
| Auto Gain Control | 50dB Variable Gain |
| Image Effects | Contrast, Sharpness, Mirror, Flip, Defog, DIS, Digital Zoom(x16) |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro) iPhone, iPad, Android support |
| Video Management | ONVIF Profile S, LILIN Navigator Enterprise 5.0, Third party VMS through LILIN HTTP API |
| SD Card (recording) | Support Micro SD/SDHC/SDXC card for circular recording (card is not included) |
| Maintenance | Firmware update via HTTP and IP Scan; Firmware available at website |
| Alarm event triggers | Alarm / motion / audio / Network lost detection |
| Alarm event actions | FTP, HTTP post, SD card |
| Network Interface/Ethernet | 10Mbps / 100Mbps , RJ-45 |
| User accounts | 10 simultaneous users |
| ePTZ & Digital Zoom | 16X |
| OSD | Text overlay for date, time, and camera name, and PTZ position |
| CPU.Memory | Embedded SoC ARM11, 528MHz, 256MB DDR2, 256MB flash memory |
| Video Display | LILIN Universal ActiveX & LILIN Java Applet |
| Network OS | Embedded Linux 2.6.32 |
| Audio | G.711 u-law |
| Protocols | IPv4, IPv6, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SNMP, Bonjour |
| Address Filter | Yes |
| Multi IP address | Yes |
| Max number of online users | 10 users accounts available |
| Access | Multiple user access levels with password protection |
| Encryption | Base64 HTTP encryption |
| Authentication | Digest HTTP authentication, RTSP authentication |
| Control Function | Pan and Tilt / Zoom and Focus / Iris and ICR / 128 Preset Position / Home Position |
| Zoom Speed | 0 - 7 Selectable[ Fast : Approx. 6.0 Second ( Tele to Wide ) in Manual Mode ] |
| Focus Speed | 0 - 7 Selectable [ Fast : Approx. 6.0 Second ( Far to Near ) in Manual Mode ] |
| Alarm Input / output | 6 Input (TTL 5Vdc) , 2 Output (0.5A 120Vac,1A 24Vac) |
| Live Video Output | CVBS 1.0 Vp-p / 75 Ω BNC |
| Warranty | 3 Years, lens and motors are limited in 1 year. |
