| Pick Up Element | 1/3 Type CMOS Sensor |
| Effective pixels | Effective pixels : 1944 (H) × 1092 (V) = 2,122,848 (pixels) ; Total number of pixels : 1956 (H) × 1266 (V) = 2,476,296 (pixels) |
| Video Compression | H.264 , Motion JPEG |
| Resolution | 1080p(1920 × 1080), 720p(1280 × 720), D1(720 × 480), CIF(352 × 240) |
| Maximum Frame Rate | H.264: up to 30 fps at SXG (1280 x 1024) / Motion JPEG: up to 30 fps at D1 (720 x 480) |
| Focal Length | 4.4mm (WIDE) 〜 132mm (TELE) |
| Iris | F1.4〜32 , Close ; Auto / Manual |
| Angle of View | Approx. 63.4°( H ) 38.51°( V ) (WIDE end), approx. 2.3°( H ) 1.33°( V ) (TELE end), (1080p mode) |
| Auto Focus | Auto / Manual |
| Zoom ratio | 30X optical zoom |
| Minimum object distance | 10 mm (WIDE end), 1.5m (TELE end) |
| Video streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video bitrate | 128 Kbps to 5 Mbps ; Frame rate and bitrate controllable on-the-fly ; VBR / CBR / GOP supported |
| Scanning System | Progressive Scan |
| Infrared Cut Filter | Colour (Day), Monochrome (Night), Auto |
| Min. illumination/Low Light Mode (Colour) | 0.4 lux (1/30 sec, F1.4(Wide), 50 IRE, AGC-Gain:45dB ICR-OFF) / 0.1 lux (1/8 sec, F1.4(Wide), 50 IRE, AGC-Gain:45dB ICR-OFF) / 0.01 lux (1/8 sec, F1.4(Wide), 50 IRE, AGC-Gain:45dB ICR-ON) |
| White Balance | ATW / Manual (1800K〜10500K) |
| Back Light Compensation (BLC) | Off / BLC / WDR |
| Electrical Shutter | Auto / manual(1/1 to 1/30,000) |
| Sense Up | Off / Auto |
| Auto Gain Control | 0 ~ 45dB |
| 3D Noise Reduction | Off / On (2D, 3D) |
| 2D WDR | Yes |
| Sharpness | Yes |
| Privacy Masking | Off / On (up to 16 areas) |
| Other functions | OFF / Mirror / Flip |
| Live Video Output | CVBS 1.0 Vp-p / 75 Ω BNC |
| Panning Range | 360° Endless |
| Panning Speed | Manual Approx. 0.1°/s ~ 120°/s 8 Steps, 16 Steps / Preset Approx. 1°/s ~ 255°/s, Alarm Trigger Speed 360°/s |
| Panning Mode | Manual , Auto , Manual Position , Sequential Position |
| Tilting Range | -6° ~ +96° |
| Tilting Speed | Manual approx. 0.15°/s〜120°/s 8 Steps, 16 Steps / Preset approx. 1°/s 〜255°/s, Alarm Trigger Speed 360°/s |
| Tilting Mode | Manual , Auto , Manual Position , Sequential Position |
| Minimum Aperture Ratio | 1 : 1.4 (Wide)〜4.6 (Tele) |
| Control Function | Pan and Tilt / Zoom and Focus / Iris and ICR / 128 Preset Position / Home Position |
| Zoom Speed | Slow / MID. / Fast Selectable [ Fast : Approx. 5.0 Second ( Tele to Wide ) in Manual Mode ] |
| Focus Speed | Slow / MID. / Fast Selectable [ Fast : Approx. 5.0 Second ( Tele to Wide ) in Manual Mode ] |
| Exposure Mode | Auto / Manual |
| Defog | OFF / ON ( Defog-1 , Defog-2 , Defog-3 , AUTO) |
| Auto Mode | OFF / AUTO / SEQ / TOUR / PATROL |
| PTZ Control | Pan, tilt, zoom-in / zoom-out, absolute position, and video-click-n-move |
| PTZ preset scheduling | Yes, via Web interface |
| Schedule Setting | OFF / AUTO / SEQ / TOUR / PATROL / Preset Position |
| Encryption | Base64 HTTP encryption |
| Access | Multiple user access levels with password protection |
| User accounts | 10 users accounts available |
| IP address filter | Yes |
| Multi IP address | Yes |
| User accounts | 8 simultaneous users |
| ePTZ & Digital Zoom | Digital zoom ratio 12X |
| OSD (On-Screen Display) | Text overlay for date, time and camera name |
| Alarm event triggers | Image upload over FTP and E-mail by alarm / motion detection |
| Alarm event actions | Yes |
| CPU | Embedded SoC ARM11, 528MHz, 256MB DDR2, 256MB flash memory |
| Firmware | Firmware upgrade via HTTP ; Firmware available to download at meritlilin.com |
| Network Interface/Ethernet | 10Mbps / 100Mbps , RJ-45 |
| CE | Yes |
| FCC | Yes |
| OS requirement | Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8 |
| Web browser | Microsoft® Internet Explorer® 6.0 and later |
| CPU requirement | Intel Pentium 4 1.8GHz or above |
| RAM requirement | 1GB or above ,Independent Display Card |
| Protocols | IP, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SNMP |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro) iPhone, iPad, Android support |
| Video Management | ONVIF Profile S ; LILIN CMX3.6 / NAV 1.0 ; Third party VMS through LILIN HTTP API |
| Video Display | LILIN Universal ActiveX & LILIN Java Applet |
| OS | Embedded Linux 2.6.32 |
| Audio | 2-way audio , G.711 / PCM |
| SD Card (recording) | Support Micro SD/SDHC/SDXC card for circular recording (card is not included) |
| Alarm Input / output | 6 Input (TTL 5Vdc) , 2 Output (0.5A 120Vac,1A 24Vac) |
| IP Rating | IP66 waterproof |
| Vandal Resistant Rating / IK Rating | IK10 impact resistant |
| Operating temperature | - 40°C – + 50°C ( -40°F – 122°F ) (AC) / - 10°C – + 50°C ( 14°F – 122°F ) (PoE+) |
| Operating humidity | 0% – 90% |
| Blower control/Fan activation | On: 35℃, Off: 25℃ |
| Heater control/Heater activation | On: 15℃, Off: 25℃ |
| Dimensions | 332mm x 210mm |
| Weight | 3200g approx. |
| Power Supply | AC24V。Power over Ethernet+ |
| PoE | PoE+ |
| Power Consumption | 37W (with heater) / PoE+ 14W |
