| Pick Up Element | 1/2.8 Type Exmor CMOS Sensor |
| Effective pixels | 1,952 (H) x 1,236 (V) = 2,412,672 (pixels) ; Effective pixels : 1,944 (H) x 1,224 (V) = 2,379,456 (pixels) |
| Video Compression | H.264 , Motion JPEG |
| Resolution | 1080p(1920 × 1080), 720p(1280 × 720), D1(720 × 480), CIF(352 × 240) |
| Maximum Frame Rate | H.264 : up to 30 fps @ 1920 x 1080, MJPEG : up to 30 fps @ 720 x 480 / H.264 : up to 30 fps @ 1280 x 720, MJPEG : up to 30 fps @ 352 x 240 / H.264 : up to 30 fps @ 1920 x 1080, MJPEG : up to 30 fps @ 1280 x 720 / H.264 : up to 30 fps @ 720 x 480, MJPEG : up to 15 fps @ 1920 x 1080 |
| Focal Length | 4.7 mm (Wide)〜94.0 mm(Tele) |
| Iris | Auto / Manual |
| Angle of View | 59.6°〜3.2°(H), 35.7°〜1.8°(V) [1080p Mode] |
| Auto Focus | Auto / Manual |
| Zoom ratio | 20X optical zoom |
| Minimum object distance | 10 mm (Wide), 1.0M (Tele) |
| Max IR distance | 150m |
| Infrared LED Angle | Automatically adjusted, Depending on the zoom ratio |
| Video streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video bitrate | 128 Kbps to 5 Mbps ; Frame rate and bitrate controllable on-the-fly ; VBR / CBR / GOP supported |
| Peak wavelength | 850nm |
| Scanning System | Progressive Scan |
| Infrared Cut Filter | Colour (Day), Monochrome (Night), Auto |
| Min. illumination/Low Light Mode (Colour) | Colour:0.4 Lux [F1.6, 1/30(1/25)Sec, 50%, AGC On];Mono:0.03 Lux [F1.6, 1/30(1/25)Sec, 50%, AGC On];IR On : 0 Lux |
| White Balance | Auto (Normal / Sodium / Mercury) / Manual (Red/Blue) |
| Back Light Compensation (BLC) | Off / On |
| Electrical Shutter | Off / Auto (256X)。Auto / Manual, 1/1(1/0.75)sec − 1/30,000sec. |
| Auto Gain Control | 0 ~ 45 dB(16 steps) |
| 3D Noise Reduction | Off / On (Level: 1〜3) |
| 2D WDR | OFF / ON |
| Sharpness | Auto / 1〜16 |
| Privacy Masking | Off / On (up to 8 areas) |
| Panning Range | 360° Endless |
| Panning Speed | Pan Manual Speed: 0.15°〜120°/s, Pan Preset Speed: 1° 〜 255°/s |
| Panning Mode | Manual , Auto , Manual Position , Sequential Position |
| Tilting Range | -5° – + 90° |
| Tilting Speed | Tilt Manual Speed: 0.15°〜120°/s, Tilt Preset Speed: 1° 〜255°/s |
| Tilting Mode | Manual , Auto , Manual Position , Sequential Position |
| Minimum Aperture Ratio | F1.6 (Wide)〜F3.5 (Tele) |
| Control Function | Pan and Tilt / Zoom and Focus / Iris and ICR / 128 Preset Position / Home Position |
| Zoom Speed | Slow / MID. / Fast Selectable[ Fast : Approx. 3.5 Sec ( Tele to Wide ) in Manual Mode ] |
| Focus Speed | Slow / MID. / Fast Selectable [ Fast : Approx. 3.5 Sec ( Far to Near ) in Manual Mode ] |
| Exposure Mode | Auto / Manual |
| Auto Mode | Off / On ( Scan / SEQ / Tour / Patrol ) |
| PTZ Control | Pan , tilt , zoom in / out , absolute position, and video-click-n-move |
| PTZ preset scheduling | Yes, via Web interface |
| Schedule Setting | Off / Auto Mode / Preset position |
| Image Effects | OFF / Mirror / Flip |
| Encryption | Base64 HTTP encryption |
| Access | Multiple user access levels with password protection |
| User accounts | 10 users accounts available |
| IP address filter | Yes |
| Multi IP address | Yes |
| User accounts | 8 simultaneous users |
| ePTZ & Digital Zoom | 12X |
| OSD (On-Screen Display) | Text overlay for date, time and camera name |
| Alarm event triggers | Image upload over FTP and E-mail by alarm / motion detection |
| Alarm event actions | Yes |
| CPU | Embedded SoC ARM11, 528MHz, 256MB DDR2, 256MB flash memory |
| Firmware | Firmware upgrade via HTTP ; Firmware available to download at meritlilin.com |
| Network Interface/Ethernet | 10Mbps / 100Mbps , RJ-45 |
| CE | Yes |
| FCC | Yes |
| OS requirement | Windows 2000 , Windows XP , Windows Vista, Windows 7, Windows 8, Windows 8.1 |
| Web browser | Microsoft® Internet Explorer® 6.0 and later |
| CPU requirement | Intel Pentium 4 1.8GHz or above |
| RAM requirement | 1GB or above ,Independent Display Card |
| Protocols | IPv4/IPv6, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, Telnet, RTSP, RTCP, Onvif, ICMP, IGMP, SNMP |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro) iPhone, iPad, Android support |
| Video Management | ONVIF Profile S ; LILIN CMX3.6 / NAV 1.0 ; Third party VMS through LILIN HTTP API |
| Video Display | LILIN Universal ActiveX & LILIN Java Applet |
| OS | Embedded Linux 2.6.32 |
| Live Video Output | CVBS 1.0 Vp-p / 75 Ω BNC |
| Audio | 2-way audio , G.711 |
| SD Card (recording) | Support Micro SD/SDHC card for circular recording (built-in Micro SD card) |
| Alarm Input / output | 6 Input (TTL DC5V) , 1 Output (0.5A AC120V,1A AC24V) |
| IP Rating | IP66 waterproof |
| Operating temperature | -40℃〜50℃ (-40℉〜122℉) |
| Operating humidity | 0% – 90% |
| Blower control/Fan activation | On: 35℃, Off: 25℃ |
| Dimensions | Ø 228mm x 347 mm |
| Weight | 4700g approx. |
| Power Supply | AC24V |
| Power Consumption | 67W |
