| Pick Up Element | 1/2.7" CMOS image sensor |
| Effective pixels | 1920 (H) × 1080 (V) = 2,073,600 (pixel) |
| Video Compression | H.264 , Motion JPEG |
| Resolution | 1080p(1920 × 1080), 720p(1280 × 720), D1(720 × 480), CIF(352 × 240) |
| Maximum Frame Rate | H.264 : up to 15 fps @ 1920 x 1080 , 30 fps @ 1280 x 720 , 30 fps @ 720 x 480 / Motion JPEG : up to 15 fps @ 1920 x 1080 , 30 fps @ 720 x 480 , 30 fps @ 352 x 240 |
| Focal Length | 4mm |
| Iris | F1.6 |
| Angle of View | 84.8°(H), 45.2°(V), 100.6°(D) |
| Max IR distance | 20M |
| Infrared LED Angle | 30〫 |
| Video streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast |
| Video bitrate | 128Kbps〜5Mbps ; Frame rate and bit rate controllable on-the-fly ; VBR / CBR / GOP supported |
| Peak wavelength | 850nm, high efficiency array |
| Window / Glass Thickness | Ø63.8 Heat Resistant Glass |
| Scanning System | Progressive Scan |
| Infrared Cut Filter | Colour (Day), Monochrome (Night), Auto, Schedule |
| Min. illumination/Low Light Mode (Colour) | 0.08 Lux at F1.6 , With Infrared 0.0 lux |
| White Balance | Auto / Tungsten / Indoor / Fluorescents1 / Fluorescents2 / Outdoor1 / Outdoor2 |
| Back Light Compensation (BLC) | On / Off |
| Electrical Shutter | 1/30(1/25)s to 1/8000s |
| Sense Up | Off / 1 frame / 2 frames / 3 frames / 7 frames |
| Sense Up+ | Yes |
| Auto Gain Control | 36 dB variable gain |
| 3D Noise Reduction | Off / 1 to 32 selectable |
| 2D WDR | Off / x2 / x3 / x4 |
| Privacy Masking | Four independent areas |
| Other functions | Sharpness, Image flip, Image mirror, Hue |
| Encryption | Base64 HTTP encryption |
| Access | Multiple user access levels with password protection |
| User accounts | 10 user accounts available |
| IP address filter | Yes |
| Multi IP address | Yes |
| User accounts | 8 simultaneous users |
| ePTZ & Digital Zoom | Yes |
| OSD (On-Screen Display) | Text overlay for date, time and camera name |
| Alarm event triggers | Motion detection triggering recording into SD card Image upload over FTP and E-mail by motion detection |
| Alarm event actions | Yes |
| CPU | Embedded SoC ARM11, 528MHz, 256MB DDR2, 256MB flash memory |
| Firmware | Firmware upgrade via HTTP |
| Network Interface/Ethernet | 10Mbps / 100Mbps Base-T, RJ-45 |
| CE | EN 55022:2010 Class A / IEC 61000-3-2:2005+A1:2008+A2:2009 / IEC 61000-3-3:2013 |
| FCC | FCC Part 15: Subpart B Class A / CISPR 22: 2008 Class A |
| OS requirement | Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8 |
| Web browser | Microsoft® Internet Explorer® 6.0 and later |
| CPU requirement | Intel Pentium 4 1.8GHz or above |
| RAM requirement | 1GB or above ,Independent Display Card |
| Protocols | IPv4, IPv6, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SNMP, SIP, Bonjour |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro) iPhone, iPad, Android support |
| Video Management | ONVIF Profile S / LILIN NAV 1.0 / Third party VMS through LILIN HTTP API |
| Video Display | LILIN Universal ActiveX & LILIN Java Applet |
| OS | Embedded Linux 2.6.32 |
| SD Card (recording) | Support Micro SD/SDHC card for circular recording (card is not included) |
| IP Rating | IP67 waterproof |
| Operating temperature | -40℃ to 50℃ (-40℉ to 122℉) |
| Chip size | 5.856mm (H) x 3.276mm (V) |
| Dimensions | Body : 87 x 72 x 125mm, Bracket : 100mm (L) |
| Weight | 630g approx. |
| Power Supply | DC12V ±10%。PoE (IEEE 802.3af compliant) |
| PoE | PoE , IEEE 802.3af |
| Power Consumption | DC12V, 5.6W / PoE, 6.5W |
