100-Meter Media Converter
Model：MC0015F
Launched
- Rugged Industrial Media Converter
- Outdoor CAM enclosure
- Mini design enclosure 59mm(L)x36mm(W)x49mm(D)
- Surge protection diodes on power input
- ESD protection diodes on RJ-45 port
- Extended environmental specification -40℃~ 75℃
The MC0015F is an industrial 100-meter media converter pairing 100BaseFX fiber (SC, ST or SFP module) with 100Base-TX copper for extended plant installations. It supports IEEE 802.3u Fast Ethernet with a 1K MAC table, 1Mbits packet buffer and IEEE 802.3x flow control plus store-and-forward processing. Power input spans 18-36VAC or 9-60VDC with full load consumption at only 1.92W@48VDC. The 59 by 36 by 49 mm housing in high-grade aluminum is rated IP40, operates from -40°C to 75°C, and meets EN60950-1, FCC, RoHS and VCCI standards.
