| Supports (Video Input)/Network video /IP video | ONVIF Profile S, LILIN IP camera, LILIN IP PTZ dome, LILIN DVR/NVR, NAV Server |
| Input(IP video input) | Up to 108 channels at 1080p/3M/4M/5M/8M |
| Network video Format | H.264 / MJPEG |
| Maximum Network Throughput | Upload: up to 500Mbps/ Download: up to 500Mbps |
| Recording schedule | 7 days x 24 hrs time table, recording mode configurable |
| Application/ Recording Mode | Alarm, motion, schedule, and manual |
| Recording speed | Max 8MP@30 fps, 5MP@12 fps, 4MP@20 fps, 3MP@15 fps, 1080p@120 fps, and ROI recording supported |
| Recording Resolution | 3840x2160, 2592x1944, 2048x1536, 1920x1080, 1280x1024, 1280x768, (720x480 / 720x576), 320x240 |
| Audio Recording | Yes |
| Circular recording | Yes / size customizable |
| Limited recording | Yes / days customizable |
| Video Archiving | Yes |
| Low bitrate recording | Yes |
| Remote Network RAID | Yes |
| Playback Search | Date, time, event, POS SmartSearch, motion SmartSearch, plate search (optional), record tagging |
| Playback Resolution | 3840x2160, 2592x1944, 2048x1536, 1920x1080, 1280x1024, 1280x768, (720x480 / 720x576), 320x240 |
| Playback Speed | FR: 1/8, 1/4, 1/2, 1X, 2X, 4X, 8X, 16X, 32X / FF: 1/8, 1/4, 1/2, 1X, 2X, 4X, 8X, 16X, 32X |
| Back up | Max. 108 channels, AVI file format supported |
| Remote video (Playback) | NAV Server/Navigator Client/DVR/NVR/IP camera SD card supported, max. 108 channels |
| Video input (Support quantity) | Max. 108 channels |
| Camera name | 20 characters |
| Channel editing | Mouse drag-n-drop |
| Digital zoom | Yes, ePTZ supported |
| Grouping (Video input) | User grouping authentication assignable for eMap, and Navigator 2.0 |
| Remote monitoring (Video input) | Yes |
| HDMI output | x 2 up to 3840 x 2160(4K) |
| Output (Video output) | ×1 (DVI-I) |
| TV Wall | Dual screen, max. 108 channels |
| Split Screen | 4, 9, 16, 25, 36 |
| Dual stream technology (Video output) | Multi-channel displays D1 and full screen displays 1080p/3M/4M/5M/8M resolution |
| Multi-screen (Video output) | Dual-screen |
| Video archiving & sync. | Individual camera configurable, scheduling and instant archiving, sync recording data with NAV server / NVR / DVR / IP camera SD card. |
| Alarm recording | Face detection, audio detection, tamper, motion, DI alarm detection, and ANPR (optional) |
| Alarm Management | Alarm popup for full screen, pc sound, redirect IP camera's digital output, email snapshots, redirect a PTZ preset recall |
| Alarm recording(Alarm / event) | Pre-alarm:1 − 5 seconds and post-alarm: 1 sec − 59 minutes |
| Alarm event actions | Various alarm log including video loss, stop recording, schedule, logon, operation log |
| Digital Output | Controllable via IP cameras |
| Keyboard Keypad | PIH-931D keyboard controllable via rs-485 for PTZ, ePTZ, and ROI features |
| Audio | PCM, two-way audio, audio recording |
| POS / barcode scanner | PS/2 |
| Protocols | ARP / TCP/IP / HTTP / SMTP / DNS / PPPoE / ONVIF |
| Mobile Application | iPhone and Android |
| IP Scan | Supported, easy-to-setup for IP address |
| CE | Yes |
| FCC | Yes |
| CPU | Intel® Core™ i7-6700 Processor |
| RAM | 4G DDR4 x 2 |
| Chipset | Intel® Q170 Chipset |
| Display card | Intel® HD Graphics 530 |
| USB port | USB 3.0 x 10 |
| System FAN | 80mm hot-swap PWM fans x 3 / 80mm rear exhaust fans x 2 |
| Raid control | LSI SAS_9361-8I |
| Raid mode | LSI Hardware, RAID 0, 1, 5, 6, 10, 50, 60 |
| SSD HDD | 120GB SATA3 SSD x1 (We suggest that you use WD Red HDD. Since the WD Purple HDD is not suitable to be used on NAS environment or RAID environment on a PC, WD Red HDD will be your best choice. The WD Datacenter HDD is suitable for a large RAID configuration environment.) |
| WDT | NAV failover / NAV monitoring station |
| DST | Daylight saving time by Windows OS |
| Languages | English, Traditional Chinese, Spanish, German, French, Russian, Japanese, Portuguese, Italian, Simplified Chinese, Czech, Slovenian, Hungarian, Turkish, Arabic, Persian, Bengali, Vietnamese |
| OS | Windows 7 embedded standard |
| Power Consumption | ATX 500W |
| Power Supply | 110V-240V |
| Operating temperature | 0°C-40°C |
| Storage temperature | -20°C-60°C |
| Storage Humidity | 10%-80% @40°C; non-condensing |
| Dimensions | 437mm x 533.4mm x 88.9mm |
| Weight | 12 Kg |
