| Min. illumination/Low Light Mode (Colour) | Color: 0.04 Lux at F1.6; B/W: 0.008 Lux at F1.6; 0 Lux with IR LED ON |
| Focal Length | 4mm |
| Minimum Aperture Ratio | F1.6 |
| Iris Control | Fixed IRIS |
| Angle of View | 86.6° (H), 46° (V), 103.4° (D) |
| Peak wavelength | 850nm |
| Beam Spread | 60° , 90° |
| Max IR distance | 50m |
| Pick Up Element | 1/2.8" CMOS image sensor |
| Effective pixels | 3864 (H) x 2176 (V) = 8,408,064 (Pixels) |
| Light sensor | Yes |
| Thermal Image sensor | Uncooled VOx microbolometer |
| Thermal Pixel Size | 12 μm |
| Thermal NETD | <50mK @ 25°C |
| Thermal Focal Length | 6.6mm |
| Thermal Minimum Aperture Ratio | F1.0 |
| Thermal Minimum Object Distance | 3.7m |
| Thermal Angle of View | 36.0° (H) 27.8° (V) |
| Thermal Wavelength | 8 - 14 μm |
| Thermal Max. Resolution | 320 x 240 |
| CE | Yes, EMI Class A |
| FCC | Yes, EMI Class A |
| UKCA | Yes, EMI Class A |
| IP Rating | IP67 |
| Vandal Resistant Rating / IK Rating | IK10 |
| CPU requirement | Intel® Core™ i7 or higher grade |
| OS requirement | Windows 7 or above |
| RAM requirement | 8GB or above, Dedicated Graphics Card |
| Web browser | Microsoft® Internet Explorer 9 or above, Microsoft® Edge |
| Audio Input / Output | Audio 1 input/output, Mono, 1.98 Vp-p, 2.2KΩ, Terminal Block |
| Audio | Two-way Audio, G.711 u-law / PCM / AAC, External Microphone Required |
| Alarm Input / output | Digital 1 input (TTL, +3-5VDC) / 1 Output (MOS Relay contact N.O., Load max. 40VDC, 450mW/300mA), Terminal Block |
| Video Compression | H.265/HEVC main profile, H.264 main and high profile, Motion JPEG |
| Video Streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast streams in H.265 and H.264 and Motion JPEG, configurable frame rate and bandwidth |
| Number of streams | 4 (Optical x2, Thermal x2) |
| Video bitrate | 128Kbps-12Mbps, Frame rate and bit rate controllable on-the-fly: VBR/CBR/GOP supported, Fixed bitrate |
| Encryption | Base64 HTTP encryption, HTTPS encryption |
| Authentication | Digest HTTP authentication, RTSP authentication, DDNS via HTTPS |
| Address Filter | Yes |
| Access | Multiple user access levels with password protection |
| Users | 10 user accounts available |
| Multi IP address | Yes |
| Resolution | Stream 1 (Optical): 3840x2160, 1920x1080, 1280x720; Stream 2 (Optical): 1280x720, 640x360; Stream 3 (Thermal): 1280x960, 640x480, 320x240; Stream 4 (Thermal): 640x480, 320x240 |
| Maximum Frame Rate | Optical: 60Hz: 25 FPS @ 3840 x 2160, 30FPS @ 1920 x 1080; 50Hz: 25 FPS @ 3840 x 2160, 25FPS @ 1920 x 1080; Thermal: 60Hz: 30 FPS @ 1280 x 960; 50Hz: 25 FPS @ 1280 x 960 |
| Scanning System | Progressive Scan |
| Infrared Cut Filter | Auto/Day (Color)/Night (Mono) / Schedule |
| White Balance | Auto/Manual one push |
| Electrical Shutter | 1/30(1/25)s - 1/30000s |
| Sense Up | Off/x2/x4/x8 |
| Sense Up+ | Yes |
| Auto Gain Control | 60 dB Variable Gain |
| S / N Ratio | More than 50dB (AGC off) |
| 3D Noise Reduction | Off/1-32 Selectable |
| High Dynamic Range(HDR) | Up to 120dB (by HDR mode, 2 shutter line interleave) |
| Privacy Masking | Off/On (4 zones) |
| Image Effects | Brightness, Contrast, Hue, Saturation, Sharpness, Mirror, Flip, Defog |
| EV (Exposure Value) | Adjustable |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro), iPhone, iPad, Android support |
| Video Management | ONVIF Profile S/ONVIF Profile T/ONVIF Profile G/ONVIF Profile M/IVS events, LILIN Navigator Enterprise 5.0 support, Third party VMS through LILIN HTTP API |
| SD Card (recording) | Support (128GB) Micro SD/SDHC/SDXC card for circular recording (card is not included) |
| Maintenance | Firmware update via HTTP and IP Scan: Firmware available at website |
| IVS Basic 1.0 | Motion/Tamper |
| Alarm event triggers | Motion / Tamper / Audio / Alarm / Network lost detection / Global Counter / Virtual Input / Metadata / Thermal measurement |
| Alarm recording(Alarm / event) | FTP/SMTP/HTTP post/SD card/SAMBA/Alarm Output/Push Service/Global Counter / Virtual Input |
| Languages | English, Traditional Chinese, Simplified Chinese, Russian, Italian, Hungarian, Korean, French, Turkish, Arabic, Spanish, Japanese |
| Ethernet | 10/100 Mbps Base-T, RJ-45 |
| OSD | Position configurable text overlay for date, time, camera ID, event status |
| CPU.Memory | Embedded Quad-core ARM Cortex-A53 1.0GHz CPU & 2GB LPDDR4X, 8GB eMMC memory |
| OS | Embedded Linux 4.14 |
| Protocols | IPv4, TCP, UDP, HTTP, HTTPS, QoS, NTP, DDNS, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, SMTP, Multicast, ONVIF Profile S, ONVIF Profile T, ONVIF Profile G, ONVIF Profile M |
| Max number of online users | 10 simultaneous users |
| Video Display | LILIN Universal ActiveX & HTML5 |
| Log | Event & operation log & IVS event log |
| Schedule Setting | Support holiday list |
| Network Storage | NAS (Support SAMBA/CIFS) |
| Starting Temperature | -10°C - +50°C (14°F - +122°F) |
| Operating temperature | -30°C - +50°C (-22°F - +122°F) |
| Storage temperature | -25°C - +60°C (-13°F - +140°F) |
| Operating humidity | 10% - 90% |
| Power Supply | DC12V ±10% (Terminal connector) / PoE+ (IEEE 802.3at compliant) |
| Power Consumption | DC12V, 12W / PoE+, 13W |
| Dimensions | 101(W) x 90(H) x 289(D) mm |
| Weight | 1100 g |
| Casing Material | Aluminum alloy |
