| Pick Up Element | 1/2.8" CMOS image sensor |
| Effective pixels | 1984 (H) x 1105 (V) = 2,192,320 pixels |
| Video Compression | H.264 , Motion JPEG |
| Resolution | 1080p(1920 × 1080), 720p(1280 × 720), D1(720 × 480), CIF(352 × 240) |
| Maximum Frame Rate | H.264 : up to 30 fps @ 1920 x 1080, MJPEG : up to 30 fps @ 720 x 480 / H.264 : up to 30 fps @ 1280 x 720, MJPEG : up to 30 fps @ 352 x 240 / H.264 : up to 30 fps @ 1920 x 1080, MJPEG : up to 30 fps @ 1280 x 720 / H.264 : up to 30 fps @ 720 x 480, MJPEG : up to 15 fps @ 1920 x 1080 |
| Focal Length | 2.8〜12 mm (zoom / focus motorized) |
| Iris | F1.4 |
| Angle of View | 91.2° – 25.5°(H), 68.4° – 19.1°(V), 114° – 31.9°(D) |
| Auto Focus | One Push |
| Max IR distance | 25m |
| Infrared LED Angle | 30〫 |
| Video streaming | RTP/HTTP, RTP/TCP, RTP/UDP, Multicast Multiple configurable streams in H.264 and M-JPEG, configurable frame rate and bandwidth |
| Video bitrate | 128 Kbps to 8 Mbps ; Frame rate and bitrate controllable on-the-fly ; VBR / CBR / GOP supported |
| Peak wavelength | 850nm, high efficiency array |
| Scanning System | Progressive Scan |
| Infrared Cut Filter | Colour (Day), Monochrome (Night), Auto, Schedule |
| Min. illumination/Low Light Mode (Colour) | 0.02 Lux / F1.4 Low Light Mode (Colour) , 0 Lux With Infrared |
| White Balance | Auto / Tungsten / Indoor / Fluorescents1 / Fluorescents2 / Outdoor1 / Outdoor2 |
| Back Light Compensation (BLC) | On / Off |
| Electrical Shutter | 1/30(1/25)s – 1/8000s |
| Sense Up | Off / 1 frame / 2 frames / 3 frames / 7 frames |
| Sense Up+ | Yes |
| Auto Gain Control | 36 dB variable gain |
| 3D Noise Reduction | Off / 1 to 32 selectable |
| 2D WDR | Off / Auto / x2 / x3 / x4 (by normal mode) |
| Privacy Masking | Four independent areas |
| Other functions | Sharpness, Image flip, Image mirror, Defog, Hue |
| Live Video Output | CVBS 1.0Vp-p, 75 ohm, RCA connector |
| Audio Input / Output | Mono, 1.4 Vp-p , 50 KΩ , 3.5mm phone jack |
| Encryption | Base64 HTTP encryption |
| Access | Multiple user access levels with password protection |
| User accounts | 10 users accounts available |
| IP address filter | Yes |
| Multi IP address | Yes |
| User accounts | 8 simultaneous users |
| ePTZ & Digital Zoom | Yes, ROI (Region of Interest) is supported |
| OSD (On-Screen Display) | Text overlay for date, time and camera name |
| Alarm event triggers | Face / tampering / audio / motion / alarm detection |
| Alarm event actions | Yes |
| CPU | Embedded SoC ARM11, 528MHz, 256MB DDR2, 256MB flash memory |
| Firmware | Firmware upgrade via HTTP |
| Network Interface/Ethernet | 10Mbps / 100Mbps Base-T, RJ-45 |
| CE | EN 55022: 2010 Class A / IEC 61000-3-2: 2005+A1: 2008+A2: 2009 / IEC 61000-3-3: 2008 |
| FCC | FCC Part 15: Subpart B (10-1-10 Edition) Class A / CISPR 22: 2008 Class A |
| OS requirement | Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8 |
| Web browser | Microsoft® Internet Explorer® 6.0 and later |
| CPU requirement | Intel Pentium 4 1.8GHz or above |
| RAM requirement | 1GB or above ,Independent Display Card |
| Protocols | IPv4, IPv6, TCP, UDP, HTTP, SMTP, NTP, DDNS, UPnP, FTP, ARP, DHCP, PPPoE, DNS, RTSP, RTCP, Telnet, ICMP, IGMP, ONVIF Profile S, SNMP, SIP, Bonjour |
| Mobile Application | Integrated to LILIN mobile app (LILIN Pro) iPhone, iPad, Android support |
| Video Management | ONVIF Profile S / LILIN NAV 1.0 / Third party VMS through LILIN HTTP API |
| Video Display | LILIN Universal ActiveX & LILIN Java Applet |
| OS | Embedded Linux 2.6.32 |
| Audio | 2-way audio , G.711 / PCM |
| SD Card (recording) | Support Micro SD/SDHC card for circular recording (card is not included) |
| Alarm Input / output | Digital 1 input (TTL, +3〜5VDC) / 1 Output (MOS Relay contact N.O., Load max. 40VDC/300mA) |
| Operating temperature | -25°C to +50°C (-13°F to 122°F) |
| Dimensions | Ø 150 x 134mm |
| Weight | 640g approx. |
| Power Supply | DC12V ±10% 。Power over Ethernet (IEEE 802.3af compliant) |
| PoE | PoE |
| Power Consumption | DC12V, 10W / PoE, 11.2W |
